High Speed Creaser | DBM-HSC
DBM-HSC is located between feeding device and DBM.DBM-HSC can slit the top and buttom margins to make full-bleeding book,and crease the paper to make flatter book and avoid the toner cracking on the booklet spine.
| Process Speed |
|---|
| 285sheets/min |
| Model/Type | High Speed Creaser DBM-HSC |
|---|---|
| Paper size | Length 170 to 640 mm Width 105 to 364 mm |
| Paper weight |
Fine quality paper 64 to 350g/m² Art/coat paper 84.9 to 350g/m² |
| Processing speed |
A4(1 crease) 220 sheets/min A5(1 crease) 285 sheets/min |
| Slitting amount | 3 to 25.4mm |
| Finished size |
Length 170 to 640mm Width 105 to 364mm |
| Power Supply | AC 100 to 240 V 50/60Hz |
| Power Consumption | 285W 0.6A |
| Dimensions | 1,385（W）×755（D）× 845（H）mm |
| Weight | 243kg |
| Options | SLITTER MODULE |
Duplo has a policy of continuous improvement and reserves the right to amend the specifications without prior notice.
