Folders｜DUPLO FOLDER DF-850
The DF-850 is a simple to use desktop folder which runs maximum 241 sheets per minute（*1）.The DF-850 provides the most folding versatility with all its features and performances.
| Paper Size | Process Speed |
|---|---|
| A3～B6 | 241sheets per minute（*1） |
（*1）For single folding 81.4gsm of fine quality A4 paper.
| Model/Type | Desktop-type DF-850 |
|---|---|
| Feeding system | ・3 rings automatic paper separation ・Slant correction device |
| Folding mode | Single fold, Double fold, Irregular accordion fold, Letter fold, Accordion fold, Gate fold, Custom fold, Special cross fold (Fine quality paper 52.3 to 104.7gsm) |
| Loading capacity of paper feed | 500 sheets (Fine quality 64gsm) |
| Folding stopper | Manual setting |
| Stacker roller | Manual setting 5 steps |
| Paper size | Min.91 (W) x 128 mm(L) Max.297 (W) x 432 mm(L) |
| Paper Type | Fine quality paper(52.3 to 157gsm), Rough paper, medium quality paper, stencil paper, specific art paper and specific coated paper |
| Paper weight | Fine quality 52.3 to 157gsm |
| Speed(Maximum) | 241 sheets/min（*1） |
| Power supply | AC 100-240V 50/60Hz |
| Power consumption | 1.3A - 0.65A |
| Dimensions | In use 900(W) x 480(D) x 535(H) mm In storage 620(W) x 480(D) x 535(H) mm |
| Weight | 31.5kg |
Duplo has a policy of continuous improvement and reserves the right to amend the specifications without prior notice.
- （*1）For single folding 81.4gsm of fine quality A4 paper.
