Die Cutter | DSM-1000

Products

This die cutter corresponds up to B2 size paper, and job settings can be easily set by entering numerical values on the PC controller screen. It can set and adjust jobs even without specialized knowledge or experience.
There is an alternative support functions such as automatic separation (cutting waste removal), paper skew correction, and cutting die-board management by using barcodes.

Process speed Paper size
Maximum 51 sheets / min
(3,100 sheets / hour)
A3 ~ B2 SEF
  • A3 ~ B2 SEF
  • Maximum 51 sheets / min (3,100 sheets / hours)
  • 40 tons

DSM-1000 Video

System-name DSM-1000 system
System configuration Configuration with separator unit (DSM-SP)
(1) DSM-SF+DSM-1000+DSM-SP+DSM-ST
Configuration without separator unit (DSM-SP)
(2) DSM-SF+DSM-1000+EJECTION SUPPORT UNIT+DSM-ST
System dimensions
(W x D x H)
Configuration with separator unit (DSM-SP)
(1) 4,166 x 1,455 x 1,395 mm
Configuration without separator unit (DSM-SP)
(2) 3,773 x 1,317 x 1,352 mm
Power supply / Maximum power consumption DSM-SF: Single phase 100V, 680w, 8.0A
DSM-1000: Three-phase 200V, 3.5kw, 20A *Peak when pressing: 10kw, 60A
Weight Configuration with separator unit (DSM-SP)
(1)3,312 kg (Including accessories)
Configuration without separator unit (DSM-SP)
(2)3,146 kg (Including accessories)
Maximum paper loading volume Maximum 400mm
Size of paper Width (W)
 279~530mm
Length (L)
 279~750mm
Paper quality High-quality paper
 127.9~209.3g/m2 *DSM-SP is available only passing
Art coated paper
 157~279g/m2 *209.4~279g/m2 when using DSM-SP
Court ball
 270~600g/m2 *270~600g/m2 when using DSM-SP
Chip ball
 400 - 650g/m2 *DSM-SP can only be passing, cannot creasing
Curl amount R120 or more / with a height of 10mm or less
Maximum processing speed 3,100 sheets/hour
Press pressure 40 tons
Cutting die Plywood thickness
 18±0.5mm
Thomson blade height
 23.6 mm (23.55~23.8mm)
Cutting die size
 520x820mm
Press area
 500x730mm
Total length of blade
 5,000mm or less
Face plate Size
 542x830mm
Thickness
 1.0mm
Separate method Scrap separation method using by rollers
Scrap removal method Free fall
Option DSM-SP
DSM-SF:SUB SUCTION UNIT
DSM-1000:REGISTRATION MARK KIT
DSM-SP:ADDITIONAL SEPARATION UNIT
STEEL COUNTERPLATES (5 SHEETS)
COVER SHEET SET
ADJUSTMENT PLATE (1.2)
ADJUSTMENT PLATE (1.5)
METAL SHIM PLATE

*Product specifications and appearance are subject to change without notice for improvement.
